IE2600A-A-25-FM

Wilson & Cousins’ IE2600A-A-25-FM:

• Field adjustable, pressure reducing angle (90-degree) valve
• UL/ULC Listed
• Forged brass construction
• Maximum inlet pressure up to 400 psi (2758 kPa)
• Maximum inlet flow rate up to 500 GPM
• Seven (7) different spring settings to set the valve

Download the Sizing Charts, Settings Calculator and Selection Guide for the IE-2600 family of valves on our Support page.

Wilson & Cousins’ IE2600A-A-25-FM:

• Field adjustable, pressure reducing angle (90-degree) valve
• UL/ULC Listed
• Forged brass construction
• Maximum inlet pressure up to 400 psi (2758 kPa)
• Maximum inlet flow rate up to 500 GPM
• Seven (7) different spring settings to set the valve
• The valve is used when the pressure at the inlet of the valve is greater than 175 psi (1207 kPa), based on NFPA 14

  Specifications Document

There are no related documents currently available for this product.

Weights and Quantities

• Case Weight: 28 lbs
• Case Quantity: 1
